SL-8 SimSlim® Multi-Parameter Patient Simulator - Pronk Technologies

SL-8 SimSlim® Multi-Parameter Patient Simulator

SL-8 SimSlim® Multi-Parameter Patient Simulator is the smallest, comprehensive multi-parameter patient simulator on the market. Includes ECG, Respiration, Arrhythmia, 4-IBP, YSI 400/700 Temperature and Cardiac Output. Its patented power circuitry provides an amazing battery life up to 10 years without charging or changing batteries! One button operation reduces time for setup and completing testing.

Back to Products
  • Description
  • Additional information

Description

SL-8 SimSlim® Multi-Parameter Patient Simulator Features:

  • 12-lead ECG:
    • 8 Selectable Heart Rates: 30, 60, 90, 120, 140, 160, 200, 240 bpm
    • 10 Selectable Arrhythmias: NSR w/ PVCs, VTACH, VFIB, Asys, Bigeminy, Pacer, Trigeminy, ST+, 2nd Deg. Block, Square Wave
    • 8 Banana Plug Interface
  • Respiration:
    • 8 Selectable Rates: 15, 30, 45, 60, 70, 80, 100, 120 bpm
  • 4 IBP Channels:
    • 8 Dynamic: 120/80, 60/30, 30/10, 20/10, 125/15, 60/5, 8/2, 4/1 mmHg
    • 7 Static: 0, 25, 50, 100, 150, 200, 250 mmHg
  • Cardiac Output Simulation:
    • 3, 5 and 7 l/m. No adapter cable required.
  • YSI 700 and 400 Temp Simulations:
    • 25, 37, and 40 degrees Celsius
  • Battery Life:
    • Total life depends on usage: 5-10 years, all day, every day. No charging or changing required.
  • 4 year warranty.

Package Contents:

    • (1) SL-8 SimSlim Simulator
    • (1) IBP adapter of customer choice
    • (1) IBP extension cable, 6ft.
    • (1) Temperature adapter cable
    • (1) Certificate of Calibration

    Optional Accessories: Additional IBP Adapters

Additional information

Brand

Pronk Technologies
