Description
Includes: SC-5 SimCube® + OX-1 OxSim® + SimSlim®
- 4 year warranty.
NIBP Simulations
- Adult (120/80 mmHg), Neonatal (70/40 mmHg), Hypertensive (190/120 mmHg), and Hypotensive (80/40 mmHg) NIBP Simulations
- Digital Manometer
- Over Pressure (Peak Detect) Test mode measures the peak pressure produced by the patient monitor. The readout latches the highest pressure valve sensed, in 0.1 mmHg steps
- Leak Rate Test Mode
ECG/Respiration Simulations
- 12-lead ECG Simulation
- 8 Selectable Heart Rates: 30, 60, 90, 120, 140, 160, 200, 240 bpm
- 10 Selectable Arrhythmias: NSR w/ PVCs, VTACH, VFIB, Asys, Bigeminy, Pacer, Trigeminy, ST+, 2nd Deg. Block, Square Wave
- 8 Selectable Respiration Rates: 15, 30, 45, 60, 70, 80, 100, 120 bpm
- Banana Plug Interface
SpO2 Simulations
- Saturation: 85, 95, 98, 99% Low Perfusion
- Pulse Rate: 40, 80, 140
IBP Simulations
- 4 IBP Channels
- 8 Dynamic: 120/80, 60/30, 30/10, 20/10, 125/15, 60/5, 8/2, 4/1 mmHg
- 7 Static: 0, 25, 50, 100, 150, 200, 250 mmHg
Cardiac Output Simulations
- 3, 5, and 7 l/m. No adapter cable required.
Temperature Simulations
- YSI 400 and 700
- 25, 37, and 40 degrees Celsius
Package Contents
- SC-5 SimCube® NIBP Simulator
- OX-1 OxSim® Optical Pulse Oximeter Simulator
- SL-8 SimSlim® Multi-Parameter Patient Simulator
- Battery Boost
- (6) NIBP Adapters
- Cuff Jacket
- (1) IBP Extension Cable
- (1) IBP Adapter Cable of your choice
- (1) Specially-modified nylon carrying case
