Description
Simple measurement of anaesthetic gases
MultiGasAnalyser OR-703 is the perfect extension to FlowAnalyser or CITREX H5 when high precission concentration measurements of anaesthetic and respiratory gases are desired. Thanks to this sensor FlowAnalyser or CITREX H5 becomes even more capable when calibrating anaesthesia machines.
The IMT Analytics MultiGasAnalyser OR-703 impresses with its compact design. The interior is characterized by state-of-the-art microsystem technology. The MultiGasAnalyser OR-703 offers flexibility in testings of anesthesia devices as well as in accuracy measurements of CO₂ concentration. The sensor measures the absorption of the infrared light at different wavelengths and is able to determin the exact gas concentration in mixed gases.
Features MultiGasAnalyser OR-703
- World’s smallest and lightest Multi-Gas Sensor
- Seamless integration of the MultiGasAnalyser with FlowLab PC software
- Maintenance-free
- Measurement values directly displayed on the FlowAnalyser or CITREX H5 screen
- Control via the RS-232 interface
Measures and displays the concentrations of the following gases:
- CO₂ // Range: 0-15% +-(0.2 vol% + 2% o.r.)/ and 15-25% unspecified
- N₂O // Range: 0-100% +-(2 vol% + 2% o.r.)
- Halothane // Range: 0-8% +-(0.15 vol% + 5% o.r.) and 8-25% unspecified
- Enflurane // Range: 0-8% +-(0.15 vol% + 5% o.r.) and 8-25% unspecified
- Isoflurane // Range: 0-8% +-(0.15 vol% + 5% o.r.) and 8-25% unspecified
- Sevoflurane // Range: 0-10 vol% +-(0.15 vol% + 5% o.r.) and 10-25% unspecified
- Desflurane // Range: 0-22 vol% +-(0.15 vol% + 5% o.r.) and 22-25% unspecified
Scope of delivery:
Multi-Gas Sensor and activation code for one FlowAnalyser or CITREX H5
For more informations, please refer to the user manual of your FlowAnalyser or CITREX H5.
